PRODUCT DETAILS
-
BRG-612Lead time
Cost
—
Corelite (Cooper Lighting Solutions)BRG. BRIDGE Fully Uniform WaveStream LED 600mm x 1200mm Recessed.
SPECIFICATIONS- DimensionsW: 2 FtL: 4 Ft
- Light SourceLED
- CCT/Color3000K3500K4000K
- CRI85
- Watt(Approx)27 W39 W47 W58 W70 W
- Lumens(Approx)3000 Lm4000 Lm5000 Lm6000 Lm7000 Lm
- OpticsDirectGeneral Diffused
- Adjustable
- Other
- DimmingDim to 3-10%Dim to 1%Step Dim0-10VFifth Light DALI
- Controls/NetworkWireless DimmingIntegral Sensor
- Power/VoltageIntegralUNV 120-277V347V
- Integral EmergencyEM Integral
- Lumen Maintenance100000 h
- CertificatesUL/CULRoHSBAA
- EnvironmentDamp
- Mounting TypeCeiling Recessed
- HousingICAir Return
- Housing Depth3.93 ''
Description:DESCRIPTIONDIMENSIONSLIGHT SOURCEWATT/LUMENSPOWER/CONTROLSYou reconfigured the product. To remove this message please update you custom description.(Approx) - Shown approximate values. Actual values may very depending on fixture configuration. Refer to manufacturer documentation for more information.
Values can be adjusted manually as required in schedule view.
SKU configuration and design parameters shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
! Marks unavailable product configuration, refer to manufacturer’s documentation for details
CONFIGURE PRODUCTPRODUCT DESCRIPTION—The Bridge™ Metric LED recessed offers a traditional yet modern design with the latest in solid-state lighting technology. High performing WaveStream™ optics allow for maximum energy savings and optimal illumination in a ultra-minimalistic shallow recessed fixture. Two WaveStream optic options are available; a fully uniform pattern and a square pattern that provides a unique translucent appearance without sacrificing performance. Additional shielding options are also available including rectangular perf, round perf, and nano-prism inlays. Available in several popular metric sizes, the Bridge is highly configurable with well-thought-out options and a number of architectural styles for application versatility.MORE DESCRIPTION
